Oxima® 2
Oxima® 2 offering highly efficient Tabletop Pulse Oximeter .
Incorporating advanced technology, Tabletop Pulse Oximeter offers excellent performance. Further, our Tabletop Pulse Oximeter is highly acclaimed for its arouses

Oxima® 2 can be applied in the hospital's operation room ICU clinic section office
Out-patient department sickroom and emergency treatment.
Oxima® 2 offering highly efficient Tabletop Pulse Oximeter .
Incorporating advanced technology, Tabletop Pulse Oximeter offers excellent performance. Further, our Tabletop Pulse Oximeter is highly acclaimed for its arouses

Oxima® 2 can be applied in the hospital's operation room ICU clinic section office
Out-patient department sickroom and emergency treatment.
Read More
Efficient performance
Easy to use
Four parameters: NIBP. SpO2. Pulse Rate. Temperature
Suitable for adult pediatric and neonatal
Battery capacity indicator and prompt when battery low
Large screen : SpO2 PR are shown on LED screen Pleth waveform is displayed on 2.8" color LCD screen in real time
24 hours or AC power and Built-in rechargeable Li-ion battery up to 5 hour running time
Storage/Review trend data up to 3888 groups data save time interval settable
Automatic shutdown for power saving shutdown time interval settable
Audio and visual alarm when parameters exceeded and sensor-off
Unique software for telemonitoring by transmitting data synchronously via internet via USB to connect with the computer

Options
Bluetooth Printer for Oxima2
Applications:
PC software for Oxima2


Oxima2 Vital signs monitor four parameters: NIBP SpO2 TEMP and Pulse Rate

NIBP:
Measurement method: Oscillometric
Range: Adult: 30mmHg~255mmHg Pediatric: 30mmHg~160mmHg
Measurement unite: MmHg/kPa selectable
Measurement mode: Manual Auto STAT
Measurement Type: SYS DIA MAP
Measurement interval in AUTO mode: 1 2 3 5 10 15 20 30 45 60Min
Measuring period in STAT mode: 5 Min
Resolution: 1mmHg
Over-pressure protection: Adult: 300mmHg Pediatric: 220mmHg

SpO2
Range: 0 -100%
Resolution: 1 %
Accuracy: 2% (90~99%) 3% (70~89%) unspecified (< 70%)

PR
Range: 30bpm~250bpm
Resolution: 1bpm
Accuracy: 2bpm
Temperature:
Channel: 1
Input: Body surface thermal-sensitive resistor temperature sensor
Measurement Unit: C/° F selectable
Range: 0~50
Resolution: 0.1
Accuracy: 0.1
Environment:

Temperature
Operation: 0C~45
Transportation and storage: -20C~60C
Humidity
Operation: 15%~95% (non-condensing)
Transportation and storage: 10%~95% (non-condensing)
Altitude
Operation: 86kPa ~ 106kPa
Transportation and storage: 50kPa~106kPa

Power Requirements:
AC power adaptor
Input: AC 100~240V 50/60Hz 0.7A
Output: 5V 2.5A
Internal battery
Type: 2.8A build-in Li-ion rechargeable battery
Operating Time: 5 hours of stand-by time with a full battery.
Recharge time: 8 hours

Dimension: 280mm × 190mm × 100mm
Net Weight: 1000g


Product Features

    Efficient performance
    Easy to use
    Four parameters: NIBP. SpO2. Pulse Rate. Temperature
    Suitable for adult pediatric and neonatal
    Battery capacity indicator and prompt when battery low
    Large screen : SpO2 PR are shown on LED screen Pleth waveform is displayed on 2.8" color LCD screen in real time
    24 hours or AC power and Built-in rechargeable Li-ion battery up to 5 hour running time
    Storage/Review trend data up to 3888 groups data save time interval settable
    Automatic shutdown for power saving shutdown time interval settable
    Audio and visual alarm when parameters exceeded and sensor-off
    Unique software for telemonitoring by transmitting data synchronously via internet via USB to connect with the computer

    Options
    Bluetooth Printer for Oxima2
    Applications:
    PC software for Oxima2



Product Specifications

    Oxima2 Vital signs monitor four parameters: NIBP SpO2 TEMP and Pulse Rate

    NIBP:
    Measurement method: Oscillometric
    Range: Adult: 30mmHg~255mmHg Pediatric: 30mmHg~160mmHg
    Measurement unite: MmHg/kPa selectable
    Measurement mode: Manual Auto STAT
    Measurement Type: SYS DIA MAP
    Measurement interval in AUTO mode: 1 2 3 5 10 15 20 30 45 60Min
    Measuring period in STAT mode: 5 Min
    Resolution: 1mmHg
    Over-pressure protection: Adult: 300mmHg Pediatric: 220mmHg

    SpO2
    Range: 0 -100%
    Resolution: 1 %
    Accuracy: 2% (90~99%) 3% (70~89%) unspecified (< 70%)

    PR
    Range: 30bpm~250bpm
    Resolution: 1bpm
    Accuracy: 2bpm
    Temperature:
    Channel: 1
    Input: Body surface thermal-sensitive resistor temperature sensor
    Measurement Unit: C/° F selectable
    Range: 0~50
    Resolution: 0.1
    Accuracy: 0.1
    Environment:

    Temperature
    Operation: 0C~45
    Transportation and storage: -20C~60C
    Humidity
    Operation: 15%~95% (non-condensing)
    Transportation and storage: 10%~95% (non-condensing)
    Altitude
    Operation: 86kPa ~ 106kPa
    Transportation and storage: 50kPa~106kPa

    Power Requirements:
    AC power adaptor
    Input: AC 100~240V 50/60Hz 0.7A
    Output: 5V 2.5A
    Internal battery
    Type: 2.8A build-in Li-ion rechargeable battery
    Operating Time: 5 hours of stand-by time with a full battery.
    Recharge time: 8 hours

    Dimension: 280mm × 190mm × 100mm
    Net Weight: 1000g
